Audi A3 (8P) 2.0 TDI Hybrid Turbo

Plug'n Play turbocharger with optimization for maximum performance

Original, new Garrett turbocharger in various Stage power levels

TurboCenter OEM turbocharger upgrade in different stage performance levels (available depending on turbocharger version):
TurboZentrum offers a wide range of optimizations and upgrades for OEM original turbochargers. Starting from Stage 1 with CNC mashined compressor wheel, up to Stage 3 with larger turbine wheel and custom turbo intakes. To withstand the power increase, all TurboZentrum Stage turbochargers have reinforced bearings and are high precise balanced after completion, which exceeds the specifications of the turbocharger manufacturers. This reduces wear and tear during operation and results in longer durability.

The Stage 1 optimization includes:

• CNC mashined & optimized compressor wheel with stock dimensions
• reinforced bearing
• can be installed without engine modifications
• optimal for chip tuning

The Stage 2 optimization includes:

• Larger CNC mashined compressor wheel
• CNC machined compressor housing
• Reinforced journal & thrust bearings
• If needed clipped turbine wheel & reinforced wastegate actuator

The Stage 3 optimization includes:

• Larger CNC mashined compressor wheel
• CNC machined compressor housing
• Reinforced journal & thrust bearings
• Larger turbine wheel
• CNC machined turbine housing
• maximum power + plug & play installation
• If needed, we can offer a customized intake

With this optimized turbocharger in the optimization, you can achieve a performance of up to 250 HP.
(Our performance data refers to the feedback of several customers and is thus an average value)

Alternative turbocharger numbers:
757042-0011 / 757042-0011S / 757042-5011 / 757042-5011S / 757042-11 / 757042-11S

You will receive here an original, new Garrett turbocharger in various performance levels!

Your used turbocharger as an upgrade

You are also welcome to send your used turbocharger to us for an overhaul and stage optimization. If the turbocharger has major defects, further costs may be added. Please contact our colleagues in TurboService for this! Ordering optimization for used turbochargers is not possible via the webshop!

Attention:
We treat every sent in turbocharger as used turbocharger. Even if you send us a new turbocharger, it will be disassembled and inspected by us, resulting in the same effort as a used turbocharger. You order a performance product from us, which meets the highest standards and is delivered by us with a 1-year warranty. Unfortunately, there are too many black sheep in the turbocharger industry, so we can not be sure whether a sent in new turbocharger is really new and / or original. Thank you for your understanding.

Required conversions

When converting to Stage turbochargers, customization of the software is recommended, and even required for Stage 2 and above. To achieve the maximum power, which the turbocharger provides, we recommend depending on the vehicle and engine a larger Y-pipe, possibly also entire exhaust system, a larger intercooler and a modified intake. Recommended for most engines is also to strengthen the engine.

Turbo Upgrade fits for the following car models:
VW Caddy III Kasten/Großraumlimousine 2.0 TDI, 2CA, 2CH, 2KA, 2KH, 2012/05-2015/05, 1968 ccm, 125 KW, 170 PS
VW Caddy III Großraumlimousine 2.0 TDI, 2CB, 2CJ, 2KB, 2KJ, 2012/05-2015/05, 1968 ccm, 125 KW, 170 PS
VW Passat 2.0 TDI, 3C2, 2005/08-2010/07, 1968 ccm, 125 KW, 170 PS
VW Golf V 2.0 TDI, 1K1, 2005/11-2008/11, 1968 ccm, 125 KW, 170 PS
VW Passat Variant 2.0 TDI, 3C5, 2005/08-2010/11, 1968 ccm, 125 KW, 170 PS
Seat Leon 2.0 TDi, 1P1, 2006/05-2012/12, 1968 ccm, 125 KW, 170 PS
Seat Altea 2.0 TDi, 5P1, 2006/03-2009/12, 1968 ccm, 125 KW, 170 PS
Audi A3 2.0 TDI, 8P1, 2006/03-2012/08, 1968 ccm, 125 KW, 170 PS
Audi A3 2.0 TDI quattro, 8P1, 2006/03-2012/08, 1968 ccm, 125 KW, 170 PS
Audi A3 Sportback 2.0 TDI, 8PA, 2006/03-2013/03, 1968 ccm, 125 KW, 170 PS
Audi A3 Sportback 2.0 TDI quattro, 8PA, 2006/03-2013/03, 1968 ccm, 125 KW, 170 PS
VW Touran 2.0 TDI, 1T1, 1T2, 2005/12-2010/05, 1968 ccm, 125 KW, 170 PS
VW Jetta III 2.0 TDI, 1K2, 2006/10-2010/10, 1968 ccm, 125 KW, 170 PS
Seat Altea XL 2.0 TDi, 5P5, 5P8, 2007/06-2009/12, 1968 ccm, 125 KW, 170 PS
VW Tiguan 2.0 TDI 4motion, 5N, 2007/09-2018/07, 1968 ccm, 125 KW, 170 PS
Seat Altea XL 2.0 TDi 4x4, 5P5, 5P8, 2007/06-2009/05, 1968 ccm, 125 KW, 170 PS
VW Passat 2.0 TDI, 3C2, 2005/08-2009/05, 1968 ccm, 120 KW, 163 PS
Seat Toledo III 2.0 TDi, 5P2, 2006/01-2009/05, 1968 ccm, 125 KW, 170 PS
Skoda Octavia II 2.0 TDi RS, 1Z3, 2006/04-2013/02, 1968 ccm, 125 KW, 170 PS
Skoda Octavia II Combi 2.0 TDi RS, 1Z5, 2006/04-2013/02, 1968 ccm, 125 KW, 170 PS
VW CC 2.0 TDI, 358, 2011/11-2016/12, 1968 ccm, 125 KW, 170 PS
Skoda Superb II 2.0 TDi, 3T4, 2008/07-2015/05, 1968 ccm, 125 KW, 170 PS
Audi TT 2.0 TDI quattro, 8J3, 2008/06-2014/06, 1968 ccm, 125 KW, 170 PS
Audi TT Roadster 2.0 TDI quattro, 8J9, 2008/06-2014/06, 1968 ccm, 125 KW, 170 PS
Skoda Superb II 2.0 TDi 4x4, 3T4, 2008/09-2015/05, 1968 ccm, 125 KW, 170 PS
VW Passat CC 2.0 TDI, 357, 2008/06-2012/01, 1968 ccm, 125 KW, 170 PS
VW Passat Variant 2.0 TDI, 3C5, 2005/08-2009/05, 1968 ccm, 120 KW, 163 PS
VW Passat 2.0 TDI, 362, 2010/08-2014/12, 1968 ccm, 125 KW, 170 PS
VW Golf VI 2.0 TDI, 5K1, 2009/04-2012/11, 1968 ccm, 125 KW, 170 PS
VW Scirocco 2.0 TDI, 137, 138, 2009/05-2017/11, 1968 ccm, 125 KW, 170 PS
VW Passat 2.0 TDI 4motion, 362, 2010/08-2013/01, 1968 ccm, 125 KW, 170 PS
Skoda Yeti 2.0 TDi 4x4, 5L, 2009/11-2015/05, 1968 ccm, 125 KW, 170 PS
Skoda Superb II Kombi 2.0 TDi, 3T5, 2009/10-2015/05, 1968 ccm, 125 KW, 170 PS
Skoda Superb II Kombi 2.0 TDi 4x4, 3T5, 2009/10-2015/05, 1968 ccm, 125 KW, 170 PS
VW Passat 2.0 TDI 4motion, 3C2, 2009/05-2010/07, 1968 ccm, 125 KW, 170 PS
VW Passat Variant 2.0 TDI 4motion, 3C5, 2009/05-2010/11, 1968 ccm, 125 KW, 170 PS
VW Passat CC 2.0 TDI 4motion, 357, 2009/11-2012/01, 1968 ccm, 125 KW, 170 PS
VW Sharan 2.0 TDI, 7N1, 7N2, 2010/08-2015/12, 1968 ccm, 125 KW, 170 PS
VW Passat Variant 2.0 TDI, 365, 2010/08-2014/12, 1968 ccm, 125 KW, 170 PS
VW Passat Variant 2.0 TDI 4motion, 365, 2010/08-2013/01, 1968 ccm, 125 KW, 170 PS
Seat Alhambra 2.0 TDi, 710, 2010/06-2015/12, 1968 ccm, 125 KW, 170 PS
VW Touran 2.0 TDI, 1T3, 2010/05-2013/01, 1968 ccm, 125 KW, 170 PS
VW CC 2.0 TDI 4motion, 358, 2011/11-2013/01, 1968 ccm, 125 KW, 170 PS
VW Passat Alltrack 2.0 TDI 4motion, 365, 2012/01-2014/12, 1968 ccm, 125 KW, 170 PS
