Race Line High-Flow Fan Mishimoto / 406mm
Features
- High-flow fan provides increased airflow
- Compact design with a housing diameter of 406mm and an Overall Thickness of 110mm provides sufficient clearance in the engine bay
- Universal fitment
- Many sizes available
Tech Specs
Type of Ends
Yazaki Tab Terminal
Material
Plastic
Note
This fan will not fit with the Mishimoto Electric Fan Mounting Kit.
Color
Black
Normal Current (amps)
18
Volts
12
Housing Diameter
406mm
Overall Thickness
110mm
Tech Specs and Sizing
Contact us
Reverse
Yes
Blade Style
Curved
Inrush Current (amps)
22.1
Number of Blades
8
Fan RPM
2000
Fan Diameter
406mm
CFM
2200
Kit Includes
Mishimoto Fan
Description
Provide your radiator with the maximum amount of airflow with our new 406mm Race Line fan. Our Race Line fans were designed for heavy-duty applications where a Slim Line fan just won't cut it. However, this robust fan is still thin enough to fit between your engine and radiator in most applications and provides 2200 CFM of airflow to cool the largest and most powerful of engines! Depending on your application, this fan can also be Reversed and used in front of your radiator.
